Industrial Robot FANUC R-1000iA/80F

FANUC R-1000iA/80F is a 6-axis high-speed industrial robot with a high payload of 80 kg. The R-1000iA/80F is ideal for a wide range of applications - from assembly and packaging to welding, and its long reach and high repeatability help reduce technical processing times and increase productivity.

Features:

Load capacity 80 kg
Large working range 2230 mm
High speed
Various mounting options

Manufacturer

Reach: 2230 mm
Payload: 80 kg

Model: R-1000iA/80F
Axes: 6

Solutions

Milling
Assembly
Packaging
Pick & Place

Get Quotation

Name/Company name

Contact number

E-mail

Request Subject

* By clicking "Send Request", you agree to our terms of use and privacy policy

Specifications

Manufacturer	Fanuc
Model	R-1000iA/80F
Reach, mm	2230
Axes	6

Payload, kg	80
Repeatability mm, mm	± 0.03
Weight kg, kg	620
Controller	R-30iB Plus

Motion range, °
J1	360
J2	245
J3	360
J4	720
J5	250
J6	720

Maximum speed, °/s
J1	170
J2	140
J3	160
J4	230
J5	230
J6	350
