Industrial Robot FANUC R-1000iA/80F
FANUC R-1000iA/80F is a 6-axis high-speed industrial robot with a high payload of 80 kg. The R-1000iA/80F is ideal for a wide range of applications - from assembly and packaging to welding, and its long reach and high repeatability help reduce technical processing times and increase productivity.
Features:
Load capacity 80 kg
Large working range 2230 mm
High speed
Various mounting options
- Manufacturer
-
- Reach
- 2230 mm
- Payload
- 80 kg
- Model
- R-1000iA/80F
- Axes
- 6
- Industries
- Solutions
Specifications
| Manufacturer | Fanuc |
| Model | R-1000iA/80F |
| Reach, mm | 2230 |
| Axes | 6 |
| Payload, kg | 80 |
| Repeatability mm, mm | ± 0.03 |
| Weight kg, kg | 620 |
| Controller | R-30iB Plus |
| Type | Articulated robot |
| Motion range, ° | |
|---|---|
| J1 | 360 |
| J2 | 245 |
| J3 | 360 |
| J4 | 720 |
| J5 | 250 |
| J6 | 720 |
| Maximum speed, °/s | |
|---|---|
| J1 | 170 |
| J2 | 140 |
| J3 | 160 |
| J4 | 230 |
| J5 | 230 |
| J6 | 350 |
