Palletizer FANUC M-410iC/315
FANUC M-410iC/315 is a high-speed palletizing robot with a payload capacity of 315 kg. Thanks to its load capacity and large working range, the M-410iC/315 is capable of stacking pallets up to 2 meters high.
Features of M-410iC/315
High payload capacity of 315 kg
Large working range of 3143 mm
High palletizing speed
- Manufacturer
-
- Reach
- 3143 mm
- Payload
- 315 kg
- Model
- M-410iC/315
- Axes
- 4
- Industries
- Solutions
Specifications
| Manufacturer | Fanuc |
| Model | M-410iC/315 |
| Reach, mm | 3143 |
| Axes | 4 |
| Payload, kg | 315 |
| Repeatability mm, mm | ± 0.5 |
| Weight kg, kg | 1600 (1300) |
| Controller | R-30iB |
| Motion range, ° | |
|---|---|
| J1 | 360 |
| J2 | 144 |
| J3 | 136 |
| J4 | 720 |
| J5 | - |
| J6 | - |
| Maximum speed, °/s | |
|---|---|
| J1 | 90 |
| J2 | 100 |
| J3 | 110 |
| J4 | 195 |
| J5 | - |
| J6 | - |
