Kuka Cobot KUKA LBR iisy 11 R1300
LBR iisy is the new and first collaborative robot from KUKA, running on the iiQKA operating system and with the KR C5 controller. LBR iisy is compact and lightweight, has 6 degrees of freedom and a working range of 600 mm, is able to precisely manipulate objects up to 3 kg, and sensors facilitate safe collaboration with people. The KUKA LBR iisy cobot is easy to operate and program, it is enough to move it by hand to set the desired coordinates, and the latest iiQKA operating system opens up incredible and previously inaccessible possibilities for automating processes with the LBR iisy cobot.
Features:
Working range 600 mm
Safe interaction with humans
Does not require protective fences
Easy to program and operate
Ability to work in limited spaces
- Manufacturer
- Reach
- 1300 mm
- Payload
- 11 kg
- Model
- LBR iisy 11 R1300
- Axes
- 6
- Industries
- Solutions
Specifications
Manufacturer | KUKA |
Model | LBR iisy 11 R1300 |
Country | Germany |
Reach, mm | 1300 |
Axes | 6 |
Payload, kg | 11 |
Repeatability mm, mm | ± 0.05 |
Weight kg, kg | 46.3 |
Mounting position | Floor, Ceiling, Wall, Desired angle |
Controller | KR C5 micro |
Type | Cobot |
Motion range, ° | |
---|---|
A1 | ± 185 |
A2 | - 230/ 50 |
A3 | ± 150 |
A4 | ± 180 |
A5 | ± 110 |
A6 | ± 220 |
Maximum speed, °/s | |
---|---|
A1 | 200 |
A2 | 200 |
A3 | 200 |
A4 | 230 |
A5 | 260 |
A6 | 430 |
Protection | |
---|---|
Protection rating (IEC 60529) | IP54 |
