Industrial Robot Kawasaki MT400N

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
3503 mm
Payload
400 kg
Model
MT400N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model MT400N
Country Japan
Reach, mm 3503
Axes 6
Payload, kg 400
Repeatability mm, mm ± 0.5
Weight kg, kg 2600
Controller F02
Type Articulated
Motion range, °
J1 ± 180
J2 + 15/-135
J3 + 106/-30
J4 ± 360
J5 ± 120
J6 ± 360
Maximum speed, °/s
J1 80
J2 70
J3 70
J4 70
J5 70
J6 130
