Industrial Robot Kawasaki duAro1

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
760 mm
Payload
2 kg
Model
duAro1
Axes
4
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model duAro1
Country Japan
Reach, mm 760
Axes 4
Payload, kg 2
Repeatability mm, mm ± 0.05
Weight kg, kg 207
Controller F61
Type SCARA
Motion range, °
Lower arm J1 ± 170
Lower arm J2 ± 140
Lower arm J3 0 mm / +150 mm
Lower arm J4 ± 360
Upper arm J1 -140 / +500
Upper arm J2 ± 140
Upper arm J3 0 mm / +150 mm
Upper arm J4 ± 360
