Industrial Robot FANUC M-20iB/25C

The FANUC M-20iB/25C has a special white paint finish that exhibits resistance to cleaning agents and is used in the typical daily cleaning operations for cleanroom environments such as the Food 2nd zone or the intermediate, optical, pharmaceutical or electronic industries. This model, based on the M-20iB series, is designed to meet the standard requirements (IP67 standard) of such demanding environments without compromising the speed and repeatability of the robot. Based on its slim, fully encapsulated design, the cleanroom robot achieves a high level of flexibility, adding flexibility to the ability to perform applications in compact cells. This cleanroom robot can achieve ISO cleanroom class 5.

Features:

  • High precision

  • Load capacity 25 kg

  • Working range 1853 mm

Manufacturer
fanuc-logo
Reach
1853 mm
Payload
25 kg
Model
M-20iB/25C
Axes
6
Get Quotation

Specifications

Manufacturer Fanuc
Model M-20iB/25C
Country Japan
Reach, mm 1853
Axes 6
Payload, kg 25
Repeatability mm, mm ± 0.023
Weight kg, kg 210
Controller R-30iB Plus
Motion range, °
J1 340 (360)
J2 240
J3 303
J4 400
J5 290
J6 540
Maximum speed, °/s
J1 205
J2 205
J3 260
J4 415
J5 415
J6 880
Protection
body IP67
wrist & J3 arm IP67
