Welding Robot Kawasaki BA013N

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
1492 mm
Payload
13 kg
Model
BA013N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model BA013N
Country Japan
Reach, mm 1492
Axes 6
Payload, kg 13
Repeatability mm, mm ± 0.04
Weight kg, kg 260
Controller F01
Type Articulated
Motion range, °
J1 ± 165
J2 + 150/-95
J3 + 90/-185
J4 ± 200
J5 ± 135
J6 ± 360
Maximum speed, °/s
J1 265
J2 250
J3 265
J4 470
J5 475
J6 730
Protection
IP67
