Industrial Robot Kawasaki RS007L

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
930 mm
Payload
7 kg
Model
RS007L
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS007L
Country Japan
Reach, mm 930
Axes 6
Payload, kg 7
Repeatability mm, mm ± 0.03
Weight kg, kg 36
Controller F60
Type Articulated
Motion range, °
J1 ± 180
J2 + 135
J3 + 157
J4 ± 200
J5 ± 125
J6 ± 360
Maximum speed, °/s
J1 370
J2 310
J3 420
J4 550
J5 550
J6 1000
Protection
Wrist IP67
Arm IP65
