Industrial Robot Kawasaki MXP710L

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
2930 mm
Payload
710 kg
Model
MXP710L
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model MXP710L
Country Japan
Reach, mm 2930
Axes 6
Payload, kg 710
Repeatability mm, mm ± 0.08
Weight kg, kg 2750
Controller F04
Type Articulated
Motion range, °
J1 ± 160
J2 + 90/-64
J3 + 40/-120
J4 ± 360
J5 ± 122
J6 ± 360
Maximum speed, °/s
J1 82
J2 70
J3 70
J4 90
J5 90
J6 160
Protection
Wrist IP67
Arm IP54
