Industrial Robot Kawasaki MXP360L

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
3234 mm
Payload
360 kg
Model
MXP360L
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model MXP360L
Country Japan
Reach, mm 3234
Axes 6
Payload, kg 360
Repeatability mm, mm ± 0.08
Weight kg, kg 1550
Controller F02
Type Articulated
Motion range, °
J1 ± 160 (± 185)
J2 + 90/-75
J3 + 50/-120
J4 ± 360
J5 ± 125
J6 ± 360
Maximum speed, °/s
J1 100
J2 86
J3 86
J4 105
J5 105
J6 165
Protection
Wrist IP67
Arm IP54
