Industrial Robot Kawasaki MG15HL

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
4005 mm
Payload
1500 kg
Model
MG15HL
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model MG15HL
Country Japan
Reach, mm 4005
Axes 6
Payload, kg 1500
Repeatability mm, mm ± 0.1
Weight kg, kg 6550
Controller E58
Type Articulated
Motion range, °
J1 ± 150
J2 + 90/-40
J3 + 30/-110
J4 ± 360
J5 ± 120
J6 ± 360
Maximum speed, °/s
J1 65
J2 33.5
J3 37.5
J4 36
J5 36
J6 80
