Industrial Robot Kawasaki BU015X

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
2887.5 mm
Payload
15 kg
Model
BU015X
Axes
7
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model BU015X
Country Japan
Reach, mm 2887.5
Axes 7
Payload, kg 15
Repeatability mm, mm ± 0.06
Weight kg, kg 590
Controller E52
Type Articulated
Motion range, °
J1 ± 180
J2 + 140/-105
J3 + 30/-170
J4 ± 210
J7 ± 110/-130
J5 ± 120
J6 ± 360
Maximum speed, °/s
J1 200
J2 200
J3 200
J4 290
J7 170
J5 280
J6 360
