Industrial Robot Kawasaki BU015N

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
1550 mm
Payload
15 kg
Model
BU015N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model BU015N
Country Japan
Reach, mm 1550
Axes 6
Payload, kg 15
Repeatability mm, mm ± 0.04
Weight kg, kg 160
Controller E51
Type Articulated
Motion range, °
J1 ± 180
J2 + 140/-105
J3 + 155/-120
J4 ± 210
J5 ± 120
J6 ± 360
Maximum speed, °/s
J1 250
J2 250
J3 215
J4 280
J5 280
J6 360
