Cobot Kawasaki CL110N

BX165N is a 6-axis hollow wrist industrial robot from Kawasaki, capable of handling objects weighing up to 165 kg. The BX165N features high speed and positioning accuracy, has an average working range of 2325 mm and is suitable for spot welding automation, machine maintenance, assembly and material handling.

Features:

  • High speed and positioning accuracy

  • Working range 2325 mm

  • Load capacity 165 kg

Manufacturer
Reach
1000 mm
Payload
10 kg
Model
CL110N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model CL110N
Country Japan
Reach, mm 1000
Axes 6
Payload, kg 10
Repeatability mm, mm ± 0.02
Weight kg, kg 42
Type Collaborative
Motion range, °
J1 ± 180
J2 ± 135
J3 ± 150
J4 ± 180
J5 ± 180
J6 ± 360
Maximum speed, °/s
J1 130
J2 130
J3 150
J4 150
J5 180
J6 180
Protection
IP66
