Industrial Robot Kawasaki ZX300S

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
2501 mm
Payload
300 kg
Model
ZX300S
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model ZX300S
Country Japan
Reach, mm 2501
Axes 6
Payload, kg 300
Repeatability mm, mm ± 0.03
Weight kg, kg 1400
Controller E02
Type Articulated
Motion range, °
J1 ± 180
J2 + 75/-60
J3 + 250/-120
J4 ± 360
J5 ± 130
J6 ± 360
Maximum speed, °/s
J1 100
J2 85
J3 85
J4 90
J5 90
J6 150
