Industrial Robot Kawasaki ZX165U

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
2651 mm
Payload
165 kg
Model
ZX165U
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model ZX165U
Country Japan
Reach, mm 2651
Axes 6
Payload, kg 165
Repeatability mm, mm ± 0.03
Weight kg, kg 1350
Controller E02
Type Articulated
Motion range, °
J1 ± 180
J2 + 75/-60
J3 + 250/-120
J4 ± 360
J5 ± 130
J6 ± 360
Maximum speed, °/s
J1 110
J2 110
J3 115
J4 140
J5 155
J6 260
