Industrial Robot Kawasaki ZX130S

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
2651 mm
Payload
130 kg
Model
ZX130S
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model ZX130S
Country Japan
Reach, mm 2651
Axes 6
Payload, kg 130
Repeatability mm, mm ± 0.03
Weight kg, kg 1350
Controller E02
Type Articulated
Motion range, °
J1 ± 180
J2 + 75/-60
J3 + 250/-120
J4 ± 360
J5 ± 130
J6 ± 360
Maximum speed, °/s
J1 130
J2 130
J3 130
J4 180
J5 180
J6 280
