Industrial Robot Kawasaki ZT130U
RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.
Features:
Compact design
High speed and positioning accuracy
Working range 903 mm
Load capacity 5 kg
- Manufacturer
- Reach
- 3230 mm
- Payload
- 130 kg
- Model
- ZT130U
- Axes
- 6
- Solutions
Specifications
Manufacturer | Kawasaki |
Model | ZT130U |
Country | Japan |
Reach, mm | 3230 |
Axes | 6 |
Payload, kg | 130 |
Repeatability mm, mm | ± 0.3 |
Weight kg, kg | 1550 |
Controller | E02 |
Type | Articulated |
Motion range, ° | |
---|---|
J1 | ± 180 |
J2 | + 60/-75 |
J3 | + 165/-95 |
J4 | ± 360 |
J5 | ± 130 |
J6 | ± 360 |
Maximum speed, °/s | |
---|---|
J1 | 105 |
J2 | 105 |
J3 | 105 |
J4 | 140 |
J5 | 135 |
J6 | 230 |
