Industrial Robot Kawasaki RS050N

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
2100 mm
Payload
50 kg
Model
RS050N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS050N
Country Japan
Reach, mm 2100
Axes 6
Payload, kg 50
Repeatability mm, mm ± 0.06
Weight kg, kg 555
Controller F02
Type Articulated
Motion range, °
J1 ± 180
J2 + 140/-105
J3 + 135/-155
J4 ± 360
J5 ± 145
J6 ± 360
Maximum speed, °/s
J1 180
J2 180
J3 185
J4 260
J5 260
J6 360
Protection
Wrist IP67
Arm IP65
