Industrial Robot Kawasaki RS013N

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
1460 mm
Payload
13 kg
Model
RS013N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS013N
Country Japan
Reach, mm 1460
Axes 6
Payload, kg 13
Repeatability mm, mm ± 0.03
Weight kg, kg 170
Controller F60; F01
Type Articulated
Motion range, °
J1 ± 180
J2 + 138/-105
J3 + 135/-159
J4 ± 200
J5 ± 125
J6 ± 360
Maximum speed, °/s
J1 265
J2 250
J3 265
J4 475
J5 475
J6 730
Protection
Wrist IP67
Arm IP67
