Industrial Robot Kawasaki RS007N

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
730 mm
Payload
7 kg
Model
RS007N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS007N
Country Japan
Reach, mm 730
Axes 6
Payload, kg 7
Repeatability mm, mm ± 0.02
Weight kg, kg 35
Controller F60
Type Articulated
Motion range, °
J1 ± 180
J2 + 135
J3 + 155
J4 ± 200
J5 ± 125
J6 ± 360
Maximum speed, °/s
J1 470
J2 380
J3 520
J4 550
J5 550
J6 1000
Protection
Arm IP67
