Industrial Robot Kawasaki RS006L

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
1650 mm
Payload
6 kg
Model
RS006L
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS006L
Country Japan
Reach, mm 1650
Axes 6
Payload, kg 6
Repeatability mm, mm ± 0.03
Weight kg, kg 150
Controller F60
Type Articulated
Motion range, °
J1 ± 180
J2 + 145/-105
J3 + 150/-163
J4 ± 270
J5 ± 145
J6 ± 360
Maximum speed, °/s
J1 250
J2 250
J3 215
J4 365
J5 480
J6 700
Protection
Wrist IP67
Arm IP65
