Industrial Robot Kawasaki RS005N

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
705 mm
Payload
5 kg
Model
RS005N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS005N
Country Japan
Reach, mm 705
Axes 6
Payload, kg 5
Repeatability mm, mm ± 0.02
Weight kg, kg 34
Controller F60
Type Articulated
Motion range, °
J1 ± 180
J2 + 135/-80
J3 + 118/-172
J4 ± 360
J5 ± 145
J6 ± 360
Maximum speed, °/s
J1 360
J2 360
J3 410
J4 460
J5 460
J6 740
Protection
Wrist IP67
Arm IP65
