Industrial Robot Kawasaki RS003N

RA005L is a 6-axis industrial welding robot from Kawasaki with a payload of 5 kg and a working range of 903 mm. RA005L is equipped with special software for arc welding, which allows you to quickly and easily program the technological process. The adaptive welding function allows you to adjust the robot's position, stroke and speed during the welding process. The flexibility and high accuracy of Kawasaki robots ensure uninterrupted quality and maximum productivity, which in turn makes them an ideal solution for arc welding automation.

Features:

  • Compact design

  • High speed and positioning accuracy

  • Working range 903 mm

  • Load capacity 5 kg

Manufacturer
Reach
620 mm
Payload
3 kg
Model
RS003N
Axes
6
Solutions
Get Quotation

Specifications

Manufacturer Kawasaki
Model RS003N
Country Japan
Reach, mm 620
Axes 6
Payload, kg 3
Repeatability mm, mm ± 0.02
Weight kg, kg 20
Controller F60
Type Articulated
Motion range, °
J1 ± 160
J2 + 150/-60
J3 + 120/-150
J4 ± 360
J5 ± 135
J6 ± 360
Maximum speed, °/s
J1 360
J2 250
J3 225
J4 540
J5 225
J6 540
Protection
IP54
